On sale Austlift 502044 – Dee Shackle 45mm 13.0T Galvanised – Grade M. Austlift grade M dee shackles are used where larger dimensional shackles are required for specific applications. Also ideal for the marine, agricultural & general industrial uses.
Grade M shackle is manufactured to comply in accordance with AS2741.
Made from Grade 40 alloy steel, larger dee shape with screw pin, available in black or hot dipped galvanised finish.
Suitable for lifting applications.
Specifications
Size: 45mm
WLL: 13.0T
Weight: 13kg
Dimensions
B: 83mm
C: 156mm
D: 44mm
D1: 51mm
F: 102mm. Browse our range of Austlift products available on sale in Australia.
