HikMicro HM-TP42-3AQF/W-POCKET2 – Pocket Thermal Imaging Camera HikMicro Australia

Description

On sale HikMicro HM-TP42-3AQF/W-POCKET2 – Pocket Thermal Imaging Camera. HIKMICRO Pocket Series is equipped with a high-resolution HIKMICRO VOx detector, an 8 MP optical camera, and a 3.5″ LCD touch screen. It helps you quickly and efficiently locate the hidden problems and accurately measure the temperatures of faults. The wide temperature range of -20°C to 400°C is ideal for building inspection, HVAC, electrical, and mechanical equipment maintenance. The 25 Hz frame rate keeps up with fast inspections, and the Wi-Fi function allows the Pocket to share images in real-time. The Pocket Series is a powerful thermography tool in your pocket, so it is always there whenever you need it.
Features
Thermal resolution: 256 x 192 (49, 152 pixels), NETD: < 40 mK [@ 25°C, F# = 1.0)
Accurately measure temperature from -20°C to 400°C l -4°F to 752°F)
Accuracy: Max. (± 2°C/3.6°F, ± 2%)
25 Hz image frequency
Thermal, fusion, PIP, and optical modes,8 MP optical camera
Manual, automatic, and 1-Tap level and span
High temperature alarm
Built-in 16 GB memory
LED work light
1.0x to 4.0x continuous digital zoom
Up to 4 hours continuous running
Specifications
Thermal Module
Detector Type: Vanadium Oxide Uncooled Focal Plane Array
IR Resolution: 256 x 192 ( 49,152 pixels)
Detector Pitch :12 pm
Spectral Range: 8 to 14 pm
NETD: < 0.04°C ( 40 mK ) at 25°C (77°F) ambient temperature, F# = 1.0
FOV (Field of View ): 50° H x 37.2° V
Image Frequency: 25 Hz
Focal Length: 3.5 mm
Focus: Fixed
Minimum Focus Distance: 0.3 m (0.98 ft)
IF0V (Spatial Resolution): 3.43 mrad
F-number: F1.1
Optical Module
Built-in Visual Camera: 3264 x 2448 (8 MP)
Focus: Fixed
FOV: 64.6° H x 51.5° V
Picture Resolution: Configurable: 2 MP, 5 MP, 8 MP
Video Resolution: 640 x 480
Image Display
Display: 640 x 480 Resolution, 3.5" LCD Touch Screen
Screen Brightness: Manual adjustment
Digital Zoom: 1.0x to 4.0x continuous
Color Palettes: 7: White Hot, Black Hot, Rainbow, Ironbow, Red Hot, Fusion, Rain
Image Modes: Thermal/Optical/Fusion/PIP
PIP: Resizable and movable infrared area on the visual image
Fusion: Thermal image with visual camera details
Level/Span: Auto/Manual/l-Tap Touch-Screen
Minimum Temp Span (Manual): 2°C (3.6°F)
Measurement and Analysis
Object Temperature Range: -20°C to 400°C ( -4°F to 752°F )
Accuracy: Max. (± 2°C/3.6°F, ± 2%), for ambient temperature from 15°C to 35°C (59°F to 95°F) and object temperature above 0°C (32°F)
Measurement Presets: Center Spot, Hot Spot, Cold Spot, Off
High Temperature Alarm: Audible/visual alarm of above temperature threshold, user-defined temperature threshold
On-Camera Emissivity Correction:Variable from 0.01 to 1.0 or selected from the materials list
On-Camera Reflected Temperature Compensation: Automatic, based on the input of the reflected temperature
On-Camera Transmission Correction: Automatic, based on the inputs for distance and humidity
Data Storage
Storage Media: Built-in EMMC (16 GB)
Image Storage Capacity: Approx. 60, 000 images
Image File Format
Radiometric.JPEG with measurement data included
Thermal.THMJPEG without measurement data included
Text Note: Max. 200 characters
Video Storage Capacity: Approx. 10 h
Video File Format: Standard MP4 non-radiometric video
Software
PC Software: HIKMICR0 Analyzer
APP: HIKMICR0 Viewer App
Cast Screen: UVC Alarm Client
Battery
Power Supply: 5 VDC/ 2 A (Charging via USB), fast charging
Power Consumption: 1.92 W
Battery Type: Rechargeable Li-ion battery
Battery Operating Time: 4 hours continuous running per battery (actual life varies depending on settings and usage)
Battery Charging Time: 1.5 h to 94%, 2.5h to full charge
Battery Charging System: In-imager charging, fast charging
AC Operation: AC operation with included power supply (100 VAC to 240 VAC, 50/ 60 Hz)
General
Wi-Fi: 802.11 b/g/n (2.4 GHz)
Bluetooth: Bluetooth 4.2
USB Interface: USB 2.0, Type-C
LED Light (torch): Yes
Microphone: Yes
Buzzer: Yes, audible alarm o…. Browse our range of HikMicro products available on sale in Australia.
